The ring hammer crusher crushes raw materials through the rapid rotation of the cone and the impact of raw materials. Large ring hammer crushers have the characteristics of simple structure, high crushing ratio, and high productivity, and can be used for dry and wet crushing. Heavy ring hammer crushers are suitable for crushing medium strength and ductility raw materials in mining, concrete, coal, metallurgical industry, decorative building materials, roads, combustion and other units. The large ring hammer crusher can adjust the castor bar gap according to the customer's regulations, and change the feed particle size distribution to meet the different requirements of different customers.
The key component in the equipment of large ring hammer crusher manufacturers is the motor rotor containing a hammer head (also known as a drill bit). The motor rotor is composed of spindle bearings, circular discs, shaft pins, and hammer heads. The motor drives the motor rotor to run at high speed in the crushing chamber. The raw materials are fed into the machine body from the upper feeding port, and are shattered due to the severe impact, impact, cutting, and grinding effects of the fast fitness hammer. At the lower side of the motor rotor, there is a grate plate. The particle size distribution of crushed raw materials that is lower than the size of the round hole sieve is discharged according to the grate plate. The coarse particle size distribution that exceeds the size of the round hole sieve is retained on the grate plate and is subjected to the severe blow and grinding of the hammer head again. Finally, the host is discharged according to the grate plate.
The key component of a large ring hammer crusher is the motor rotor containing the ring hammer. The motor rotor is composed of components such as a ring hammer shaft and a ring hammer. The motor drives the rotor part of the motor to run at high speed in the crushing chamber. The raw materials that need to be crushed are transmitted from the upper feeding port to the machine, and are crushed due to the severe impact of the high-speed moving ring hammer, as well as the impact, extrusion, and grinding effects between the raw materials.
PCH ring hammer crusher is a new type of ring hammer crusher equipment. The PCH ring hammer crusher manufacturer's equipment is suitable for crushing various raw materials with ductility, hardness, and low moisture content. PCH ring hammer crusher is mainly used to crush minerals such as coal, gangue brick, sandstone, Diabase, dolomite, and gypsum in the industrial production of decorative building materials, metallurgical industry, chemical plants, and Fossil fuel power station. The PCH ring hammer crusher manufacturer's equipment series products have the characteristics of stable operation, reliability, long service life, compact structure, low smoke and dust, low noise, light weight, convenient maintenance, low power consumption, and strong ability to discharge superhard raw materials.
The large ring hammer crusher itself is mainly composed of the following components: template support part, motor rotor part, castor plate part, synchronous adjustment equipment, top cover hydraulic press opening equipment, and other components. The server is connected to the motor by the Fluid coupling and operates immediately. The heavy-duty ring hammer crusher is immediately driven by an electric motor. Through a coupling device, the water pump flywheel (also known as a half coupling device) drives the motor rotor body to rotate rapidly. The motor rotor body is composed of the motor rotor disc, shaft pin, and hammer ring. The hammer ring not only rotates rapidly with the motor rotor, but also rotates uniformly around the shaft pin for fitness exercises. The hammer ring contains convex teeth and is a component that immediately crushes raw materials
